T-Motor Velox F7 SE 8S+V70A SE Stack AM32 8S 4IN1 Stack

T-Hobby Velox F7 SE 8S + V70A SE 8S 4-in-1 ESC Stack

Extreme 8S Power. Open-Source AM32 Control.

The T-Hobby Velox F7 SE 8S + V70A SE Stack is a heavy-duty, high-voltage powerhouse engineered to push the boundaries of modern FPV performance. Upgraded with native support for up to 8S battery input, this combo unlocks up to a 50% increase in maximum thrust while delivering a massive electrical headroom threshold for safer operations under high load. Designed with unified plug-and-play wiring following strict Betaflight socket standards, it streamlines clean layout integration while preventing incorrect wire positioning.

At the core of the stack is the high-velocity STM32F722 processor paired with an ICM-42688-P gyro via high-speed SPI. The flight controller integrates a huge 128MB onboard flash Blackbox chip—providing eight times the storage capacity of standard budget boards—allowing pilots to record extensive flight log streams without constant clearing. Power stability is managed by a third-generation dual BEC circuit that slashes ripple voltage by 50% compared to previous designs, filtering electrical noise up to 90dB to provide clean, low-latency data straight to your gyroscope.

The companion 4-in-1 V70A SE ESC runs open-source AM32 firmware on an upgraded 32-bit chip architecture to sustain an enormous 70A continuous current. Built on an optimized multi-layer PCB layout that limits structural resistance and maximizes thermal dissipation, it provides stable performance across high-stress racing and long-range tracking lines. Whether assembling an aggressive 5-inch freestyle weapon or a heavy 10-inch long-range cinematic lifter, the Velox 8S stack delivers incredible headroom.

Key Features

• Native 8S Voltage Headroom: Upgraded electrical system supports up to 8S configurations, generating up to 50% more raw thrust power.

• Massive 128MB Blackbox Logging: Offers a huge memory footprint for long-duration PID and filter tuning logs.

• 70A AM32 32-Bit ESC Architecture: Utilizes highly customizable, open-source AM32 firmware for high PWM frequencies and extended flight efficiency.

• Third-Gen Ripple-Filtering BEC: Reduces voltage ripples by 50% and isolates up to 90dB of power lines noise for smooth gyro data.

• Full Plug-In Signal Interface: Interconnects using clean, structured ribbon wire sockets that eliminate messy hand soldering between boards.

• Integrated Wireless Bluetooth Module: Enables on-the-field wireless parameter changes using mobile phone configuration tools.

Technical Specifications

VELOX F7 SE 8S Flight Controller

• MCU: STM32F722

• Gyroscope: ICM-42688-P (SPI)

• Firmware Target: TMTR-T-MOTORHOBBYVELOXF7

• Input Voltage: 12V–34V (3S–8S LiPo)

• BEC Output: 5V @ 2A & 10V @ 1.5V

• Blackbox Memory: 128MB Onboard Flash

• UART Ports: 6x Hardware UARTs

• Motor Outputs: Supports up to 8 Motors

• Dimensions: 37.5mm $\times$ 40mm $\times$ 6.4mm

• Mounting Holes: 30.5mm $\times$ 30.5mm ($\varnothing4\text{mm}$)

• Weight: 9g

VELOX V70A SE 8S 4-in-1 ESC

• Processor Chip: Upgraded 32-Bit Architecture

• Firmware Core: Open-Source AM32

• Continuous Current: 70A

• Peak Burst Current: Upgraded Headroom Architecture

• Input Voltage Threshold: 3S–8S LiPo Native

• PCB Layout: Optimized Multi-Layer High-Current Power Layers

• Mounting Layout: 30.5mm $\times$ 30.5mm ($\varnothing4\text{mm}$)

Includes

• 1 x T-Hobby Velox F7 SE 8S Flight Controller

• 1 x T-Hobby Velox V70A SE 8S 4-in-1 ESC

• 1 x Stack Connector Wiring Harness

• 1 x High-Quality Power Capacitor

• 1 x XT60 Heavy-Duty Power Lead Pigtail

• 1 x Anti-Vibration Silicone Dampening Grommet Set
